This 385EK Wood Furnace can easily heat up to about 2,000 square feet.
Other factors including the square footage of your home, your home's age, design, and geographic location and climate may affect your heating needs. Another factor to consider is your furnace chimney's draft strength. It's important to choose a solid fuel heating furnace that is correctly sized for your residential home. An undersized wood furnace will need to be fired more often, while an oversized wood furnace will be less efficient and could contribute to dangerous creosote buildup.
EnergyKing 385EK Wood Furnace Specifications:
• Dimensions (HxWxD): 48"x26"x53"
• Weight (approx.): 875 lbs.
• BTU Capacity* (approx.): 125,000 BTU
• Heating Area* (approx.): 2,000 Sq Ft
• Log Length: 26"
• Sliding Smoke Baffle: Standard
• Fuel Door Size (H x W): 12.5" x 14"
• Ash Door Size (H x W): 7.25" x 11.5"
• Removable Ash Pan: Standard
• Flue Size: 6"
• Flue Collar Height (to top): 45"
• Leg Height: 3.5"
• Plenum Outlet Size: 18" x 18"
• Insulated Cabinet: Standard
• Double Wall Back: Standard
• Prewired Components: Standard
• Air Draft Controls: Automatic / Manual
• Wall Thermostat: Standard
• Optional. 3-Speed Blower
• Filter Box: Optional
• Cast Stationary Grates: Standard
• Cast Rocker Grates: Optional
• Cast Hearth Plates: Standard
• Warranty: 6-Year Limited
• Complies with Test Standards UL391
Wood Furnace Safety & Reliability:
All EnergyKing Wood Furnaces are constructed of high quality 1/4", 7 gauge and 10 gauge steel plate welded by experienced and certified welders to ensure safety and durability.
EnergyKing Wood Furnaces are
tested to UL391 standards. You can rest easy knowing that EnergyKing Wood Furnaces conform to an internationally recognized standard for safety and quality.
Wood Furnace Draft Options:
• Auto Draft Automatic Draft (standard): When your home cools, the wall thermostat activates the automatic draft motor to open the draft damper, allowing your chimney’s natural draft to pull combustion air into the burn chamber. When your home reaches the desired temperature, the automatic draft motor closes the draft damper.
• Manual Draft The Manual Draft system is controlled by adjusting the manual draft dial. By opening or closing the draft dial, you can manually control the amount of air entering the burn chamber of your ENERGY KING 365EK Wood/Coal Furnace.
Wood Furnace Grate Options:
• All EnergyKing Wood/Coal Furnaces come standard with stationary cast iron grates. Optional cast iron shaker grates are available.
• Optional cold air return Filter Box Kit provides air filtration for your cold-air return system.
